TH-06 Heavy-Duty Electric Linear Actuator for Universal Applications
TH-06 Universal Heavy-Duty Linear Actuator for All Scenarios adopts a thickened full aluminum alloy casing body design, with classic silver-black industrial color matching, thick texture and firm structure. It has an IP54 protection rating and has passed CE and ROHS environmental safety certifications, making it a highly versatile heavy-duty actuator. The core parameters perform excellently, with a push force of 6000N, pull force of 4000N, self-locking force of 4000N, 24VDC DC input, full-load working current of 4A, and uniform no-load telescopic speed of 5mm/s, which can adapt to most medium to heavy linear push-pull working conditions.
The product is equipped with a high-power DC brushed motor, matched with a thickened metal reduction gearbox, with abundant torque output and stable and reliable operation. It is built-in with electronic limit switches and full-range overload protection, which automatically cut off power at both ends of the stroke to prevent impact damage, effectively extending the service life of the product. The trapezoidal lead screw is firmly self-locking, supports loads without sliding when stopped, and the 10% intermittent duty cycle is suitable for continuous industrial start-stop operations. The whole machine has no oil pollution, saves the supporting consumables of cylinders and oil pumps, and has standardized flange mounting holes, which are suitable for various installation scenarios, convenient to install and highly versatile.
The product is oriented to general heavy automation, medical nursing beds, greenhouse window openers, sanitation vehicle covers, industrial assembly line pusher equipment and other scenarios, supports customization of thrust, stroke and mounting connectors, and can flexibly adapt to the use needs of different scenarios. It is the most versatile heavy-duty actuator model, which can fully replace traditional pneumatic and hydraulic cylinders, providing clean and efficient linear actuation solutions for various industries.
